| Camera |
| Image Sensor: |
1/2.8" Progressive Scan CMOS |
| Signal System: |
PAL/NTSC |
| Min. Illumination: |
Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR，Color: 0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter time: |
1/3 s to 1/100,000 s |
| Slow shutter: |
Support |
| Lens: |
2.8 mm, horizontal field of view: 108° |
| 4 mm, horizontal field of view: 86.4° |
| 6 mm, horizontal field of view: 52° |
| 8 mm, horizontal field of view: 41° |
| 12 mm, horizontal field of view: 25° |
| Lens Mount: |
M12 |
| Adjustment Range: |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Day& Night: |
IR cut filter with auto switch |
| Wide Dynamic Range: |
120 dB |
| Digital noise reduction: |
3D DNR |
| Focus: |
Fixed |
|
Compression Standard
|
| Video Compression: |
H.265+/H.265/H.264+/H.264/MJPEG |
| Video bit rate: |
32Kbps~16Mbps |
| Triple Streams: |
Yes |
|
|
| Max. Image Resolution: |
1920 x 1080 |
| Frame Rate: |
50Hz: 50fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| 60Hz: 60fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub Stream: |
50Hz: 25fps (640 × 480, 640 × 360, 352 × 288) |
| 60Hz: 30fps (640 × 480, 640 × 360, 352 × 240) |
| Third Stream: |
50Hz: 25fps (1920 × 1080, 1280×720, 640 × 360, 352 × 288) |
| 60Hz: 30fps (1920 × 1080, 1280×720, 640 × 360, 352 × 240) |
| Image Enhancement: |
BLC/3D DNR/HLC |
| Image Settings: |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| ROI: |
Support 1 fixed region for main stream and sub stream separately |
| Day/Night Switch: |
Day/Night/Auto/Schedule |
|
Network
|
| Network Storage: |
microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger: |
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Protocols: |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
| General Function: |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy |
| mask, Watermark, IP address filtering |
| System Compatibility: |
ONVIF (Profile S, Profile G), ISAPI |
|
Interface
|
| Communication Interface: |
1 RJ45 10M / 100M Ethernet interface |
| On-board storage: |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
|
Smart Feature-set
|
| Behavior Analysis: |
Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection |
| Line Crossing Detection: |
Cross a pre-defined virtual line |
| Intrusion Detection: |
Enter and loiter in a pre-defined virtual region |
| Unattended Baggage: |
Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
| Object Removal: |
Objects removed from the pre-defined region, such as the exhibits on display. |
| Exception Detections: |
Scene change detection |
| Recognition: |
Face Detection |
|
General
|
| Operating Conditions: |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) |
| Humidity 95% or less (non-condensing) |
| Power Supply: |
12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption: |
12 VDC ± 25%, 5W |
| PoE(802.3af, class 3), 6.5W |
| Weather Proof: |
IP67 |
| IR Range: |
Up to 30m |
| Dimensions: |
Camera: Φ70 × 155.03 mm (Φ2.76″ × 6.1″) |
| Package: 216 × 121 × 118 mm (8.5″ × 4.76″ × 4.65″) |
| Weight: |
Camera: 410 g (0.9 lb.) |
